Wood Framing App

$29.95$29.99

NOT available for AutoCAD LT.

Clear
SKU: woodframingapp Categories: , ,

Description

Description

3D Wood Framing Plans

If you create Wood Framing Plans in 3D, then this app will definitely save you a huge amount of time. Create a Wood Framing 3D model using a single line to represent the framing elements of the model. Use a single line to represent the wood stud center-lines and the wood stud is then inserted using the center insertion point. For Wood Floor Joists use the top of wall line and the wood joists are inserted using the bottom insertion point. Rafters can be inserted using the top or bottom insertion points.
Select your Wood Framing type, click OK then select the lines to be framed. Each Wood shape is extruded along the line selected for a fast framing solution.

Wood Beam-Column Types:
Choose from a variety of preset LVL’s, 2x’s, 4x’s, and 8x’s or just enter the width and height of the beam or column you require not listed in the pre-sets.

Wood Beams Options:
Choose one of three Wood Beams Options including Single, Double, or Triple beams or columns.

Insertion Points:
Insertion Point selections for each beam or column, for all selected framing lines, can represent the Center, Top, or Bottom of the framing beam or column.

  • Installation (click to open for more info)

    Installation

    Download the file from the link provided in the sales receipt and save the file to your computer hard disk.  After downloading locate the file and execute it to install the program. Restart AutoCAD for the plug-in to autoload and become active. An icon will appear in the “Add-Ins” or “Plug-Ins” tab of the Ribbon Panel for this App.

    Uninstall

    The installer that ran when you downloaded this plug-in has already installed the plug-in. You may need to restart the Autodesk product to activate the plug-in. To uninstall this plug-in, click Control Panel > Programs > Programs and Features (Windows 7/8/8.1) or Control Panel > Add or Remove Programs (Windows XP), and uninstall as you would any other application from your system.

  • Software Activation

    Software Activation

    You have 15-days to activate the software. When running in non-activated mode a dialog will only appear once the first time the program is executed in a new or existing drawing which indicates the number of Days Remaining before the program stops and an option to Activate. Until you are ready to activate the software, you can run the software in the Non-Activated mode before it expires by clicking on the “Continue without Activation” button.

    To activate the software, when you open a new or existing drawing and a dialog appears prompting you to press “OK” button to Activate Now. This takes you to the SoftDraft Activation dialog showing your License Code and an edit box for you to enter the License Key. To receive your License Key, click in the License Code edit box, then copy the License Code. To avoid mistakes, we suggest that you copy it from this dialog and paste it in an email, instead of entering it with the keyboard, then send it to

    Please include the name the app was purchased under and company name. After we receive the email we will send the License Key back, usually within 24 hours, for you to enter into the dialog. Copy the License Key from the email into the License Key edit box area of the Activation dialog, then click “OK” to close the dialog. An alert will show the License Key was or accepted or an incorrect Key was entered. If you receive the “Incorrect License Key” alert, please notify tech support in an email to support @ softdraft.com

Additional information

AutoCAD Version

2018, 2017, 2016, 2015, 2014, 2013, 2012
