Steel Valves 2D-LT 2024

For AutoCAD LT 2024 Version Only.
Prices are in US Dollars

$149.00

SKU: steel_valves_2d-lt Category:

Description

Steel Valves 2D-LT 2024 Version Only
AutoCAD 2024 now with AutoLISP capabilities!
This version is now available for AutoCAD LT 2024 Version.
NOT COMPATIBLE with any of the Pre-2024 AutoCAD LT versions.

Steel Valves 2D-LT 2024 is a software application that allows you to quickly and easily place steel valves in various 2D views. It is compatible with AutoCAD and does not require any data manuals.

To use Steel Valves 2D-LT 2024, simply select the desired valve type, view, and handle position from the dialog box. The software will then automatically generate the valve.

Steel Valves 2D-LT 2024 supports a wide range of valve types, including gate valves, globe valves, and butterfly valves. It also supports a variety of views, including plan view, elevation view, and section view. Steel Valves 2D-LT 2024 can be used to place valves in any orientation, including horizontal, and vertical.

Steel Valves 2D-LT 2024 is a valuable tool for architects, engineers, and contractors who need to create accurate and detailed steel valve drawings. It is easy to use and can save you a significant amount of time.

Here are some of the features of Steel Valves 2D-LT 2024:

  • Quick and easy to use
  • Compatible with AutoCAD LT 2024 Version
  • No data manuals required
  • Supports a wide range of valve types
  • Supports a variety of views
  • Can be used to place valves in any orientation

If you are looking for a software application that can help you quickly and easily place steel valves in various 2D views, then Steel Valves 2D-LT 2024 is the perfect solution for you.

Gate Valve Dialog

Includes 457 flanged, threaded and buttweld valves:
“Ball Valves” from 1/4″ to 12″
“Butterfly Valves” from 2″ to 12″
“Check Valves” from 2″ to 24″
“Gate Valves” from 2″ to 24″
“Globe Valves” from 2″ to 14″
“Plug Valves” from 1/2″ to 24″

Iron Globe Valve

Flanges 150#, 300#, 400#, 600#, 900# 1500# and 2500#:
Blind
Weld Neck
Threaded
Slip On
Lap joint



Additional information

Your CAD Program

AutoCAD

Your CAD Version

Full Version, Upgrade From Your Previous Version
